SKU
R40-TC

Track connector

Track connector steel zinc
USD$2.30
Stocks
Farnham: 834
Los Angeles: 674
Lawrenceville: 1152
  • Electric conductivity (ESD)
  • Connect rails one after another up to 16 feet length
  • Compatible with other 1 1/16 in (28mm) pipe and joint systems

The R40-TC is an ESD metal track connector to make conveyor extensions. You can use this part to extend an 8-foot track up to 16 feet. However, we don't recommend to use this product multiple times to connect more than two rails. If you require creating bigger flow rack, it's preferable to use the R40-TU.

According to the lean principles, building multiple smaller flow racks will be much more efficient than a single giant flow rack.

See the Installation Steps tab for more information on how to install this conveyor accessory.

All Flexpipe conveyor R40 accessories are engineered to perfectly fit the R40-RT96.

The Flexpipe roller track and its accessories will work on any 28mm pipe and joint systems. Some systems don't have the same conveyor size, so be sure to check the spec sheet to see if your old conveyor parts are compatible.

Learn more on different accessories configuration on the How to build modular flow racks page. Every part of the Flexpipe conveyor system is ESD, allowing you to build antistatic structures for the transportation of electronics and electrical components.

Don't know where to begin? Our flow rack starter kit could be really helpful!

More Information
Units per box (sold separately)40
Length inches4 3/4 in (120 mm)
Height inches1 5/8 in (41mm)
Width inches1 5/8 in (41 mm)
Depth inches1 3/8 in (35.5 mm)
Unit weight pounds0.34 lb (0.155 kg)
Box dimensions inches11 X 9 X 5 po (279mm X 229mm X 127mm)
Total height inches1 3/8 in (35.5 mm)
Compatible support systemsCreform, NIS, C Tek, Fastube
Compatible conveyor systemsCreform, NIS, C Tek, Fastube small wheel conveyors
Noncompatible conveyor systemsTrilogiq
RecyclableYes
Compatible pipe systemsFlexpipe, Creform, Fastube
Noncompatible pipe systemsTrilogiq
ReusableYes
Electric conductivity (ESD)Yes
MaterialAcier roulé à chaud (SPHC)
Steel hardness (HRB)0.65
FinishShiny
System operational temperature-148°F to 428°F (-100°C to 220°C)
Steel treatmentGalvanized
Manufacturing techniquePressed and deburring
Additional reinforcement holeNo
Rail materialHot rolled steel (SPHC)
    1. Ensure you have the following parts:
    2. Insert the first R40-RT96 halfway into the R40-TC.
    3. Insert the second R40-RT96 into the empty half of the R40-TC.
    4. Fasten the 4 self-tapping screws into the R40-TC to secure it will not moving on the R40-RT96
