SKU
H-24NP

3 way cross hinge joint

3 way cross hinge joint steel cr
USD$1.44
Stocks
Farnham: 2210
Los Angeles: 928
Lawrenceville: 3220

The H-24NP is an anti-static metal single joint needed to create joint sets known as HJ-24NP. This joint is mostly used to create joints that work best in the center of structures.

The H-24NP was built with six internal striations for optimal grip on the pipe's outer coating.

The H-24NP is compatible with most 28mm pipe systems and equivalent joints.

More Information
Units per box (sold separately)150
Unit weight pounds0.224 lbs (0.102 kg)
Box dimensions inches11 X 9 X 5 in (279mm X 229mm X 127mm)
Compatible joint systemsFlexpipe, Creform
Noncompatible joint systemsTrilogiq, Fastube
Noncompatible joint systemsTrilogiq, Fastube
RoHS certificationYes
RecyclableYes
Compatible pipe systemsFlexpipe, Creform, Fastube
Noncompatible pipe systemsTrilogiq
Frequency of useVery Low
ReusableYes
Electric conductivity (ESD)Yes
MaterialHot rolled steel (SPHC)
Steel hardness (HRB)0.65
FinishShiny
UV resistanceHigh
System operational temperature-40°F à 122°F (-40°C à 50°C)
Steel treatmentNickel electroplating
Manufacturing techniquePressed and deburring
