SKU
H-90

Round joint

Round joint steel black
USD$1.22
Stocks
Farnham: 11709
Los Angeles: 9093
Lawrenceville: 17095
  • Connector used to assemble the HJ-90 joint set
  • Compatible with 28 mm pipes
  • 100 units per box (please order individually)

The H-90 is a black metal single joint used to assemble the HJ-90 joint set. This piece is commonly used to create a 90-degree angle. Combined with a second H-90, it becomes very useful for creating ergonomic cart handles.

Technical Informations:
This connector is designed with 4 striations for a better on the plastic coating of the 28 mm pipes. It also includes 2 additional pre-drilled reinforcement holes to ensure extra strength to your structure. By adding a self-drilling screw F-A85/8, you will solidify the connector joints positioned on a corner where there is a higher risk of impact.

Antistatic Version (ESD):
An electric conductivity version if offered if you wish to build antistatic structures: H-90NP

Want to reuse parts of your old system?
The H-90 Flexpipe joint is compatible with many other pipe and connector systems. Check the technical information tab to know which systems are compatible and none-compatible with our parts.

All our joints are sold individually.
To make is easier for you, we indicated the quantity included in a box if you want to order a complete box. However, our order system consider single amount only. Please enter the total amount of joint you wish to receive (example; 100 units = 1 box).

More Information
Units per box (sold separately)100 units per box
Length inches3 1/8 in (79 mm) on each side
Height inches3/4 in (19 mm)
Width inches1 5/16 in (33 mm)
Depth inches1 5/16 in (33mm)
Steel thickness inches1/8 in (2.5mm)
Unit weight pounds0.224 lbs (0.102 kg)
Box dimensions inches11 X 9 X 5 in (280mm X 225mm X 130mm)
Compatible joint systemsCreform, NIS, C Tek Lean Solutions, Trilogiq (28 mm)
Noncompatible joint systemsFastube, Trilogiq (28.6 mm)
Noncompatible joint systemsTrilogiq, Fastube
RoHS certificationYes
RecyclableYes
Compatible pipe systemsCreform, Fastube, Trilogiq (28 mm), NIS (28 mm), C Tek Lean Solutions (28 mm)
Noncompatible pipe systemsTrilogiq (28.6 mm)
Frequency of useHigh
ReusableYes
Electric conductivity (ESD)No
MaterialHot rolled steel (SPHC)
Steel hardness (HRB)68-75 HRB
FinishGlossy
UV resistanceHigh
System operational temperature-148°F to 572°F (-100°C to 300°C)
Steel treatmentBlack cathodic electrodeposition (Ecoating)
Manufacturing techniqueStamping and deburring
Striations for grip4 striation grip lines
Positioning guide2 positioning guide lines
Additional reinforcement hole2 reinforcement holes
