SKU
H-23NP

Parallel hinge joint

Parallel hinge joint steel cr
CDN$1.05
  • Connector used to assemble the HJ-23NP joint set
  • Compatible with 28 mm pipes when used with an AP-HINGE bracket
  • 120 units per box (please order individually)
  • Electric conductivity (ESD) joint

The H-23NP is a chrome plated single joint with antistatic properties (ESD) used to assemble the HJ-23NP joint set. This piece is a different version of the H-13NP that can be assembled on an AP-HINGE bracket to create a swivel 90-degree angle. Without the hinge, the H-23 can't be assembled on 28 mm pipes. Make sure you have enough AP-HINGE in inventory when you choose this piece.

Non-Electric Conductivity Version:
A black version of this item if offered without antistatic properties: H-23

Want to reuse parts of your old system?
The H-23NP Flexpipe joint is compatible with many other pipe and connector systems. Check the technical information tab to know which systems are compatible and none-compatible with our parts.

All our joints are sold individually.
To make is easier for you, we indicated the quantity included in a box if you want to order a complete box. However, our order system consider single amount only. Please enter the total amount of joint you wish to receive (example; 120 units = 1 box).

More Information
Best SellerNo
Units per box120 units per box
Length inches3 3/16 in (81 mm)
Height inches3/4 in (19 mm)
Width inches1 5/16 in (33 mm)
Depth inches1 5/16 in (33mm)
Steel thickness inches1/8 in (2.5mm)
Unit weight pounds0.141 lbs (0.064 kg)
Box dimensions inches11 X 9 X 5 in (280mm X 225mm X 130mm)
Compatible joint systemsCreform, NIS, C Tek Lean Solutions, Trilogiq (28 mm)
None compatible joint systemsFastube, Trilogiq (28.6 mm)
None compatible joint systemsTrilogiq, Fastube
RoHS certificationYes
RecyclableYes
Compatible pipe systemsCreform, Fastube, Trilogiq (28 mm), NIS (28 mm), C Tek Lean Solutions (28 mm)
None compatible pipe systemsTrilogiq (28.6 mm)
Frequency of useVery Low
ReusableYes
Electric conductivity (ESD)Yes
MaterialHot rolled steel (SPHC)
Steel hardness (HRB)68-75 HRB
FinishShiny
UV resistanceHigh
System operational temperature-148°F to 572°F (-100°C to 300°C)
Steel treatmentChrome plating
Manufacturing techniqueStamping and deburring
Striations for grip2 striation grip lines
Positioning guideNone
Additional reinforcement holeNone
