White 8' steel pipe
- Galvanized steel pipe covered with white polyethylene (PE)
- 1 1/16 in (28 mm) diameter
- 96 in (2438 mm) length
- Take advantage of our cutting service.
The P-96 is a 1 1/16 in (28 mm) external diameter galvanized steel pipe coated with colored polyethylene. To minimize shipping costs and maximize maneuverability, most of the pipes are 8 feet (2438 mm) long.
It is recommended to consult the page How to calculate the loading capacity before designing your structures. You will be able to calculate your structural capacity before a permanent deflection.
P-96 has two electric conductivity (ESD) versions:
All the P-96 pipes of the Flexpipe system are compatible with most other 28 mm systems on the market. This allows any surplus left by your previous systems to be used.
CUTTING SERVICE
Pre-cut service is now available for this product. Read more about our pre-cut service to find out how you can add it to your order.
| Units per package (sold separately) | 10 |
|---|---|
| Length inches | 96 in (2438.4 mm) |
| Pipe outside diameter inches | 1 1/16 in (27.6 mm ± 0.2 mm) |
| Pipe inside diameter inches | 15/16 in (23.4 mm ± 0.1 mm) |
| Coating thickness inches | 1/16 in (1.1 mm ± 0.1 mm) |
| Steel thickness inches | 1/16 in (1.0 mm ± 0.02 mm) |
| Unit weight pounds | 3.724 lbs (1.69 kg) |
| Package dimensions inches | 96 1/2 X 4 1/4 X 2 1/4 in (2451 mm X 108 mm X 57 mm) |
| common uses | Carts, Racks, Flow Racks, Workstations, Boards |
| Compatible joint systems | Flexpipe, Creform, Fastube |
| Noncompatible joint systems | Trilogiq |
| Noncompatible joint systems | Trilogiq |
| RoHS certification | Yes |
| Recyclable | Yes |
| Reusable | Yes |
| Electric conductivity (ESD) | No |
| Material | Cold rolled steel (SPCC) |
| Steel hardness (HRB) | 70 |
| Steel grade | Q235 |
| Welding process | High frequency welding |
| Steel pipe treatment | Galvanized |
| Coating material | Polyethylene (PE) |
| Finish | Matte |
| UV resistance | Good |
| System operational temperature | -40°F to 122°F (-40°C to 50°C) |
Use white pipe if your industry requires a high level of cleanness such as electronic, electric or food industries.
