45 angle A joint

45 angle A joint steel black
Farnham: 4275
Los Angeles: 5461
Lawrenceville: 7610
  • Connector used to assemble the HJ-17 joint set
  • Compatible with 28 mm pipes
  • 145 units per box (please order individually)

The H-17 is a black metal single joint used to assemble the HJ-17 joint set. Combine with the H-18 joint, this piece becomes a 45-degree angle connector.

Technical Informations:
This connector is designed with 4 striations for a better on the plastic coating of the 28 mm pipes. It also includes 2 additional pre-drilled reinforcement holes to ensure extra strength to your structure. By adding a self-drilling screw F-A85/8, you will solidify the connector joints positioned on a corner where there is a higher risk of impact.

Antistatic Version (ESD):
An electric conductivity version if offered if you wish to build antistatic structures: H-17NP

Want to reuse parts of your old system?
The H-17 Flexpipe joint is compatible with many other pipe and connector systems. Check the technical information tab to know which systems are compatible and none-compatible with our parts.

All our joints are sold individually.
To make is easier for you, we indicated the quantity included in a box if you want to order a complete box. However, our order system consider single amount only. Please enter the total amount of joint you wish to receive (example; 145 units = 1 box).

More Information
Box Quantity145
Length3 3/16 in (81 mm)
Height3/4 in (19 mm)
Width1 5/16 in (33 mm)
Weight0.152 lb (0.069 kg)
Box DimensionsCardboard box of 11 X 9 X 5 in (279 mm X 229 mm X 127 mm)
Compatible brandCreform, NIS, C Tek Lean Solutions, Trilogiq (28 mm)
Non Compatible BrandFastube, Trilogiq (28.6 mm)
Primary MaterialHot rolled steel (SPHC) with black cathodic electrodeposition (Ecoating)
Temperature Resistance-148°F to 572°F (-100°C to 300°C)
Electric Conductivity (ESD)No
Manufacturing TechniqueStamping and deburring
