SKU
P-157-YW
Yellow 4 m PE Coated Steel Pipe
Yellow 4 meters steel pipe PE coated
CDN$14.60
Stocks
Farnham: 176
- Galvanized steel pipe coated with yellow high-density polyethylene (HDPE)
- 1 1/16 in (28 mm) diameter
- 157,48 in (4000 mm) length
The P-157 is a 1 1/16 in (28 mm) external diameter galvanized steel pipe coated with colored high-density polyethylene and the pipes are 157,48 inch. (4000 mm) long.
It is recommended to consult the page How to calculate the loading capacity before designing your structures.
P-157 has two electric conductivity (ESD) versions:
All the P-157 pipes of the Flexpipe system are compatible with most other 28 mm systems on the market. This allows any surplus left by your previous systems to be used.
| Box Quantity | 200 |
|---|---|
| Length | 157 in (3988 mm) |
| Outside Diameter | 1 1/16 in (27.6 mm ± 0.2 mm) |
| Inside Diameter | 15/16 in (23.4 mm ± 0.1 mm) |
| Material Thickness | 1/16 in (1.0 mm ± 0.02 mm) |
| Weight | 5.566 lb (2.530 kg) |
| Box Dimensions | 157 1/2 X 4 1/4 X 2 1/4 in (4000 mm X 108 mm X 57 mm) |
| Common Usage | Carts, racks, flow racks, workstations, boards |
| Compatible brand | Creform, Fastube |
| Non Compatible Brand | Trilogiq |
| Primary Material | Cold rolled steel (SPCC) |
| Secondary Material | High density polyethylene (HDPE) |
| Temperature Resistance | -40°F to 122°F (-40°C to 50°C) |
| Electric Conductivity (ESD) | No |
| Manufacturing Technique | High frequency welding |
| Pantone | 7406C |
