Description

Benefits

  • Best way to ease your team into using this equipment - parts and plans in 1 package
  • No more headaches of making sure that you have all the necessary parts
  • No unnecessary leftover units

What’s included

  • Most frequently used parts to build the structures, in sufficient quantity and ratio count
  • Structure-specific components (e.g. conveyors for flow racks)
  • Updated parts list (if applicable)

You will need

  • Tool to cut your pipe to the desired length. If you don't have any saw at your facility, we recommend the following tool to start: T-CUTTER
  • For more information on which tools we recommend to build your project, read our blog articles Top 4 tools for cutting and Top 5 tools for assembling

Do you need to add a surface to your structure? See  Deckings

List of Kit Products:

  • 1 × POSTER-BOX — poster 24''X36''
  • 10 × H-13 — Parallel Joint Steel
  • 4 × H-14 — Double Pivot Joint Steel
  • 10 × H-15 — Upper Clamp Joint Steel
  • 10 × H-16 — Lower Clamp Joint Steel
  • 60 × H-2 — Inner Corner Joint Steel
  • 60 × H-3 — Outer Corner Joint Steel
  • 10 × H-4 — Cross Junction Joint Steel
  • 24 × H-5 — Pivot Point Joint Steel
  • 48 × H-6 — Pivot Extension Steel
  • 8 × H-6A — Extended Pivot Joint Steel
  • 10 × H-90 — Round Joint Steel
  • 1 × HAN-NIC — Handle
  • 10 × M6-12B — Bolt for HJ-15 Set
  • 400 × M6-25B — Bolt for Joint Sets
  • 400 × M6-N — Nut for Joint Sets
  • 48 × R40-MS — R40 Roller Track Mounting Bracket Start
  • 12 × W-4ESB — 4" Swivel Stem Caster with Brake
  • 6 × W-4PSB — 4" Swivel Plate Caster with Brake
  • 2 × WF-LPLATE — Left Side Caster Plate Installation
  • 2 × WF-RPLATE — Right Side Caster Plate Installation
  • 1 × STARTER-BOX
  • 1 × AW-DUCT — PVC Wiring Duct 6 ft
  • 60 × P-96-BL — Blue 8 ft PE Coated Steel Pipe
  • 24 × R40-RT96 — Roller Track Steel 40 mm x 8 ft ESD
  • 6 × R40-GUIDE — R40 8 ft Roller Track Lateral PVC Plastic Guide
  • 2 × W-4PF — 4" Rigid Plate Caster
  • 16 × WF-UP — Installation Bracket for 4" Caster - UPPER
  • 16 × WF-LOW — Installation Bracket for 4" Caster - LOWER
  • 32 × M8-N — Lock Nut for Caster White Zinc
  • 32 × M8-45B — Bolt for 6" and 8" Casters White Zinc
  • 1 × AW-MOUNT — Monitor VESA Mounting Plate
  • 1 × D-5SFOAM2040 — 5s Kaizen Foam 13 layers 2.4" x 20" x 40"
  • 1 × D-PEGW-4814 — 1/4" White HDPE Peg Board Sheet 48" x 96"
  • 2 × D-HDPEB-4812 — 1/2" Black HDPE Sheet 48" x 96"
  • 32 × F-W516 — Washer for Caster Mounting Plates

Technical Information

More Information
Box Quantity 1
