Monitor mounting plate
- Compatible with 28 mm pipes
- Assembly required
- Can be used to fix monitors to workstation
The AW-MOUNT is an accessory that can be used to attach a monitor or television to a pipe and improve the efficiency of your workstations.
The AW-MOUNT will mount most standard size monitors or televisions.
|Units per box (sold separately)||1|
|Length inches||4 ⅞ in (123.8 mm)|
|Width inches||4 ⅞ in (123.8 mm)|
|Depth inches||1/16 in (1.6mm)|
|Unit weight pounds||0.892 lbs (0.405 kg)|
|common uses||Computer monitors and TV for workstation|
|Compatible joint systems||Creform, NIS, C Tek Lean Solutions, Trilogiq (28 mm)|
|Noncompatible joint systems||Fastube, Trilogiq (28.6 mm)|
|Compatible pipe systems||Creform, Fastube, Trilogiq (28 mm), NIS (28 mm), C Tek Lean Solutions (28 mm)|
|Noncompatible pipe systems||Trilogiq (28.6 mm)|
|Electric conductivity (ESD)||No|
|Material||Hot rolled steel (SPHC)|
|Steel hardness (HRB)||68-75 HRB|
|Coating material||Powder coating|
|Steel treatment||Black cathodic electrodeposition (Ecoating)|
|Manufacturing technique||Laser cut and deburring|
|Striations for grip||4 striation grip lines|
|Additional reinforcement hole||1 reinforcement hole|
1. Screw the plate to the screen
2. Position the plate where you want it on the pipe
3. Position the H-15 and tighten it in the desired position
